Graphtec CE6000 Plus Series Vinyl Cutters

Intuitive, Easy to Operate Vinyl Cutters with High Quality Results

Graphtec CE6000 Plus Series – the built-in front control panel provides complete parameter control including eight preset cutting conditions, as well as advanced features like tangential control mode, down force offset, pen up speed, blade wear monitoring and more. With a 25 pin RS-232C or the High Speed USB 2.0 control interface, a newer, larger LCD screen, managing your cutting jobs is simpler than ever!

Graphtec CE6000 Plus Series comes standard with: floor stands (except for the 15″ CE-6000-40 model comes with rear media roll rack), Cutting Master Plug-in, plus Graphtec’s ARMS (Automatic Registration Mark Sensor) system.

The Perfect Intermediate Vinyl Cutting Solution for the Education Environment

Choose from three sizes

  • Features

3.7 inch wide user-friendly LCD control Panel

Setting can be easily configured using the large LCD (3.7-inches, 240×128 dots) and tactile control panel. It is also icon driven and supports 10 languages.

High adaptability to the operating environment

The design of the media feed system ensures that loaded media is acclimated to the ambient temperature and humidity before plotting or cutting. The user-selectable media pre-feed function sets two outer tracks, enhancing media handling. Together, these two media feed elements ensure reliable cutting and plotting quality within the desired operating environment

Easy to use in simple operation mode

Two set up menus: simple and normal are available an can be chosen by the operator as desired.

Dual tool configuration and easy switching between cutting and plotting

The pen carriage holds both a plotting pen and a blade at the same time — to enable easy switching between plotting and cutting operations. Four sets of user-specified setup parameters are retained in memory for instantaneous recall. The pen is for plotting and detailing graded patterns with seams, text, notches, Grain direction, etc.

Enhanced speed when cutting

Innovative features include maximum cutting speeds of 39 ips and with a maximum cutting force of 450g. It also features an easy to use menu navigation system with eight groups of preset conditions which facilitates instantaneous recall of pre-programmed job-specific plotter setups.

Tri-port connectivity (USB, parallel and serial) makes the CE6000 Plus Series compatible with virtually any computer configuration.

Reliable long length tracking up to 196.85 inchs long

The built-in front control panel provides complete parameter control including eight preset cutting conditions, as well as advanced features like tangential control mode, down force offset, pen up speed, blade wear monitoring and more. With a 25 pin RS-232C or the High Speed USB 2.0 control interface, the CE6000 Plus Series is compatible with legacy computer systems as well as the latest PCs available now and for several years to come.

ARMS 5.0 for high precision cutting in the print and cut application

ARMS is an abbreviation for Advanced Registration Mark Sensing system, which uses sensors to detect registration marks and performs the AXIS ALIGNMENT.

It is able to adjust received contour cutting data in the cutting plotter to align with the printed image. It enables to significantly improve productivity in the Print & Cut applications that makes stickers or decals.
